Reliable Ground Support Products for Aviation Operations
PowerAll Systems, LLC delivers high-performance ground support products built for demanding aviation environments. Our solutions are engineered to support efficient, safe, and cost-effective maintenance for turbine-powered aircraft and helicopters worldwide. From advanced ground support equipment for aircraft maintenance to innovative cleaning and power solutions, every product is designed with durability, ease of use, and real-world functionality in mind.
Products
Advanced Turbine Engine Wash Systems
Our industry-leading turbine engine wash system lineup is designed to streamline maintenance while maximizing engine performance. The trusted TW60 turbine engine wash system and its counterpart, the TW60AT, provide flexible operation for both hangar and ramp use.
Each system includes:
Each system includes:
- Durable hardline piping and bulkhead fittings
- A 25-foot hose for extended reach
- Dual five-gallon tanks for solution and water
- Easy front-panel valve control for fluid selection
The TW60 turbine engine wash system operates using shop air, making it a dependable option for standard maintenance setups. The TW60AT offers added versatility with a built-in compressed air tank, while still allowing shop air integration when needed. These ground support products ensure thorough and efficient turbine engine cleaning in any environment.
Portable Ground Power Units for Maximum Efficiency
Our portable ground power units are designed to support both aircraft starting procedures and maintenance operations. These hybrid systems deliver consistent, reliable power whether operating independently or connected to a 110/220 single-phase AC source.
PAS-2400WEIGHT
PA-2400 GPU 86 LBS
DC POWER CABLE 8.5 LBS
DC POWER CABLE .4 LBS
INPUT POWER AC
120 VOLTS AC 15.0 AMPS MAX
220 VOLTS (SINGLE PHASE) 15.0 AMPS MAX
OUTPUT POWER DC
POWER CELLS 24VDC
PEAK OUTPUT 2400 AMPS
CONTINUOUS 25 AMPS
WITH AC POWER 28.5+ VDC
WITHOUT AC POWER 25 VDC
POWER CELL
DRY CELL AGM LEAD ACID
HIGH DISCHARGE RATE
FAST RECHARGE
MAINTENANCE FREE
DC POWER CABLE
LENGTH 8FT
AIRCRAFT CONNECTOR 3 PIN RECEPTICLE
PAS-2400-50WEIGHT
PA-2400 GPU 94 LBS
DC POWER CABLE 8.5 LBS
DC POWER CABLE .4 LBS
INPUT POWER AC
120 VOLTS AC 20.0 AMPS MAX
220 VOLTS (SINGLE PHASE) 20.0 AMPS MAX
OUTPUT POWER DC
POWER CELLS 24VDC
PEAK OUTPUT 2400 AMPS
CONTINUOUS 25 AMPS
WITH AC POWER 28.5+ VDC
WITHOUT AC POWER 25 VDC
POWER CELL
DRY CELL AGM LEAD ACID
HIGH DISCHARGE RATE
FAST RECHARGE
MAINTENANCE FREE
DC POWER CABLE
LENGTH 8FT
AIRCRAFT CONNECTOR 3 PIN RECEPTICLE
Our versatile 'Dual Unit' GPUs are can be split apart and used separately with the purchase of an additional DC Cable and optional Single Cart.
PAS-4500WEIGHT
PA-2400 GPU (2x) 86 LBSX2 = 172 LBS.
DC POWER CABLE 8.5 LBS
DC POWER CABLE .4 LBS
INPUT POWER AC
120 VOLTS AC 20.0 AMPS MAX
220 VOLTS (SINGLE PHASE) 20.0 AMPS MAX
OUTPUT POWER DC
POWER CELLS 24VDC
PEAK OUTPUT 4500 AMPS
CONTINUOUS 50 AMPS
WITH AC POWER 28.5+ VDC
WITHOUT AC POWER 25 VDC
POWER CELL
DRY CELL AGM LEAD ACID
HIGH DISCHARGE RATE
FAST RECHARGE
MAINTENANCE FREE
DC POWER CABLE
LENGTH 8FT
AIRCRAFT CONNECTOR 3 PIN RECEPTICLE
PAS-4500-100WEIGHT
PA-2400-50 GPU (96LBSX2) 170 LBS
DC POWER CABLE 8.5 LBS
DC POWER CABLE .4 LBS
INPUT POWER AC
120 VOLTS AC 20.0 AMPS MAX
220 VOLTS (SINGLE PHASE) 20.0 AMPS MAX
OUTPUT POWER DC
POWER CELLS 24VDC
PEAK OUTPUT 4500 AMPS
CONTINUOUS 100 AMPS
WITH AC POWER 28.5+ VDC
WITHOUT AC POWER 25 VDC
POWER CELL
DRY CELL AGM LEAD ACID
HIGH DISCHARGE RATE
FAST RECHARGE
MAINTENANCE FREE
DC POWER CABLE
LENGTH 8FT
AIRCRAFT CONNECTOR 3 PIN RECEPTICLE
Dual Unit GPUs
- Maintenance-free, non-hazmat AGM lead-acid batteries
- Continuous power supply for extended operations
- 8-foot DC cables and 6-foot AC cables
- Separate carts with pneumatic wheels for easy mobility
This ground support equipment for aircraft maintenance solutions provides unmatched convenience and performance, helping teams maintain productivity in fast-paced aviation settings.
High-Quality Ground Support Solutions You Can Trust
From advanced wash systems to dependable portable ground power units, our full range of ground support products is built to meet the evolving needs of aviation professionals. Every product reflects our commitment to quality, innovation, and value.
Connect with PowerAll Systems, LLC today to learn more about our ground support equipment for aircraft maintenance, request a quote, or find the right solution for your operations.
